Seneca R-KEY-LT - Product Features

User Manual
R-KEY-LT
ALL RIGHTS RESERVED. NO PART OF THIS PUBLICATION MAY
BE REPRODUCED WITHOUT PRIOR PERMISSION.
www.seneca.it
Doc. MI004870-EN
Rev. 1.0.0.0
Page 4
DEVICE DESCRIPTION AND INTENDED USE
WARNING!
This User Manual extend the information from the installation manual about the device configuration.
Use the installation manual for more info.
WARNING!
Under any circumstances, SENECA s.r.l. or its suppliers shall not be responsible for loss of recording
data/incomes or for consequential or incidental damage due to neglect or reckless mishandling of the
device, even though SENECA is well aware of these possible damages.
SENECA, its subsidiaries, affiliates, companies of the group, its suppliers and retailers shall not
guarantee that the functions will satisfy completely customer’s expectations or that device, the
firmware and the software shall have no errors or work continuously.
1.1. FEATURES
 NR 1 RS485-RS232 serial port
 NR 1 Fast Ethernet 10-100 Mbits with auto TX/RX
 Up to 8 Modbus TCP-IP client in Modbus Ethernet to Serial mode
 Up to 10 Modbus TCP-IP server in Modbus Serial to Ethernet mode
 Support up to 247 Modbus serial slave devices
 Simple configuration from the internal Webserver
 Traffic Serial Packets Monitor from the internal Webserver
 Support for Modbus RTU and Modbus ASCII serial protocols
 Discovery Tools for search and configure devices (without changing the PC ip configuration)
 DHCP / Static IP / Factory default available from dip switches SW2
 Compact size: overall dimensions less than 110 x 53 x 32 mm
 Baud rate for Modbus RTU/ASCII: from 1200 baud up to 115200 baud
 Firmware Update from the internal webserver
 Polarizer for RS485 BUS available from dip switches SW1
 Quick installation on DIN 46277 rail
