The EK 2000 diversity receiver
The frequency bank system
The receiver is available in 5 UHF frequency ranges with up to
3,000 receiving frequencies per frequency range:
Each frequency range (Aw–Dw, Gw) offers 26 frequency banks with up to
64 channels each:
Each of the channels in the frequency banks “1” to “20” has been factory-
preset to a fixed receiving frequency (frequency preset). The factory-
preset frequencies within one frequency bank are intermodulation-free.
These frequencies cannot be changed.
For an overview of the frequency presets, please refer to the supplied
frequency information sheet. Updated versions of the frequency informa-
tion sheet can be downloaded from the EK 2000 product page on our
website at www.sennheiser.com.
The frequency banks “U1” to “U6” allow you to freely select and store
receiving frequencies. It might be that these receiving frequencies are not
intermodulation-free (see page 30).
500 600 700 800
Range
Gw:
558 – 626
Range Bw:
626 – 698
Range
Cw:
718 – 790
Range Dw:
790 – 865
516 – 558
Range
Aw:
Frequency bank 1 ... 20
Frequency bank U1 ... U6
Channel 64 – frequency preset
Channel 1 – frequency preset
Channel 2 – frequency preset
Channel 64 – freely selectable frequency
Channel 1 – freely selectable frequency
Channel 2 – freely selectable frequency
