SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26 SERIES
Page 3
Feb 10/10
23-41-48
Different Cables can be connected to the headset of the HMEC 26 series. The Cables have the following
components. Table 2 gives the components and functions of the different Cables.
MODEL NO. DESCRIPTION PART NUMBER
Cable -V-RP Cable with a 6-pin Redel connector, a control unit to adjust the volume,
an on/off NoiseGard™ switch, a mono/stereo switch and an L/R boom switch,
NoiseGard™ powering via panel
-999-3661
Cable -CP Cable with an XLR-5 connector and a control unit to switch NoiseGard™ on/off,
NoiseGard™ powering via panel
-999-3211
Cable -V-CP Cable with an XLR-5 connector, a control unit to adjust the volume,
an on/off NoiseGard™ switch and an L/R boom switch, NoiseGard™ powering via panel
-999-3251
Cable -NP Cable with an 8-pin neutricon connector and a control unit to switch NoiseGard™ on/off,
NoiseGard™ powering via panel
-999-3811
Cable -KP Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent
and a control unit to switch NoiseGard™ on/off, NoiseGard™ powering via panel
-999-3111
Cable -V-KP Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent,
a control unit to adjust the volume and switch NoiseGard™ on/off, a mono/stereo switch
and an L/R boom switch, NoiseGard™ powering via panel
-999-3161
Cable -V-KX Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent,
an XLR-3 powering connector, a control unit to adjust the volume and switch NoiseGard™
on/off, a mono/stereo switch and an L/R boom switch, NoiseGard™ powering via panel
-999-4161
Cable -BV-K Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent,
a control unit to adjust the volume and switch NoiseGard™ on/off, a mono/stereo switch,
an L/R boom switch, an Auto Shut-Off function, a 3.5 mm jack socket for an external audio
unit and a 2.5 mm jack socket for a mobile phone, NoiseGard™ powering via battery
-999-1171
Cable -BV-KP Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent,
a control unit to adjust the volume and switch NoiseGard™ on/off, a mono/stereo switch,
an L/R boom switch, an Auto Shut-Off function, a 3.5 mm jack socket for an external audio
unit and a 2.5 mm jack socket for a mobile phone, NoiseGard™ powering via panel and
battery possible
-999-2171
Cable -B-CP Cable with an XLR-5 connector, a control unit to switch NoiseGard™ on/off and
an Auto Shut-Off function, NoiseGard™ powering via panel and battery possible
-999-2291
Cable -BV-CP Cable with an XLR-5 connector, a control unit to adjust the volume and switch NoiseGard™
on/off, an L/R boom switch and an Auto Shut-Off function, NoiseGard™ powering via panel
and battery possible
-999-2281
Cable -B-K Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack equivalent,
a control unit to switch NoiseGard™ on/off and an Auto Shut-Off function, NoiseGard™
powering via battery
-999-1191
Cable -B-KP Cable with a 6.3 mm stereo jack (PJ-055 equivalent), a PJ-068 microphone jack
equivalent, a control unit to switch NoiseGard™ on/off and an Auto Shut-Off function,
NoiseGard™ powering via panel and battery possible
-999-2191
Table 2
Equipment Cable covered
