Specifications
Set 880 | 47
Transmitter, model: TR 880
Power supply unit, model: NT 5-10AW
Charging adapter, model: MCA 800
Hearing profiles 1-5
Connections
digital input: optical
supported data streams:
PCM, 32 - 96 kHz/16 - 24 bit
analog input:
3.5 mm jack socket
input voltage range:
0.15 to 4.0 V
pk
Power supply 5 V , 1 A
Power consumption
operation: typ. 1 W
standby:
≤ 0.5 W
(without charging)
Dimensions (W x H x D) approx. 50 x 42 x 270 mm
Nominal input voltage/cur-
rent
100 – 240 V~/300 mA
Power frequency 50 – 60 Hz
Nominal output voltage 5 V
Nominal output current 1 A
Temperature range
operation: 0 °C to +40 °C
storage: -25 °C to +70 °C
Relative air humidity (non-
condensing)
operation: 10 to 80 %
storage: 10 to 90 %
Maximum value of the
static magnetic field at the
surface
22 mT
Profile 1
Profile 2
Profile 3
Profile 4
Profile 5
Lows Midrange Highs
Tiefen Mitten Höhen
10
5
0
-5
-10
-15
-20
0 Hz 0.25 0.5 1 21.5 3 4
Frequency/kHz
6
Gain/dB
