9
Putting the bodypack transmitter into operation
Connecting the microphone cable/instrument cable
The audio input is designed for the connection of both condenser micro-
phones and instruments (e.g. guitars). DC powering of the condenser
microphones is via the audio input MIC/LINE (3-pole special audio
socket).
왘 Use one of the recommended Sennheiser microphones or the CI 1-4
instrument cable (see “Accessories” on page 33).
왘 Connect the 3-pin special audio connector from the Sennheiser
microphone or instrument cable to the socket MIC/LINE .
왘 Lock the 3-pin special audio connector by screwing down the coupling
ring .
왘 Via the operating menu, adjust the sensitivity of the microphone/line
input (see page 20).
