4
The SK 2000 bodypack transmitter
Overview of the microphones and instrument cables:
The frequency bank system
The bodypack transmitter is available in 5 UHF frequency ranges with up
to 3,000 transmission frequencies per frequency range:
Each frequency range (Aw-Dw, Gw) offers 26 frequency banks with up to
64 channels each:
Microphone/instrument cable Type
Pick-up pattern
MKE 1 clip-on microphone
condenser
omni-directional
ME 102 clip-on microphone cardioid
ME 104 clip-on microphone cardioid
ME 105 clip-on microphone super-cardioid
HSP 2 headmic omni-directional
HSP 4 headmic cardioid
CI 1-4 instrument cable – –
500 600 700 800
Range
Gw:
558 – 626
Range Bw:
626 – 698
Range
Cw:
718 – 790
Range Dw:
790 – 865
516 – 558
Range
Aw:
Frequency bank 1 ... 20
Frequency bank U1 ... U6
Channel 64 – frequency preset
Channel 1 – frequency preset
Channel 2 – frequency preset
Channel 64 – freely selectable frequency
Channel 1 – freely selectable frequency
Channel 2 – freely selectable frequency
