IoT into the Wild
47
Step 2: Loosen the screw lightly until the gears on the opposite side separated from lock
position.
Step 3: Adjust the vertical angle of the solar panel (0°, 15°, 30°, 45°, 60°) according to the
latitude of your location.
Step 4: Push the gear and tighten the screw until the gears are securely locked.
