Flowmeter Assemblies
The 2-in. gas owmeter assembly is available in three different styles to accommodate standard, high, and
low ow rates. See Table 3.1 below for the part numbers for these assemblies.
Table 3.1—Gas Flowmeter Assemblies
Part Number Description
9A-100003397 Gas meter assembly, low ow range
9A-100003398 Gas meter assembly, standard ow range
9A-100003399 Gas meter assembly, high ow range
Spare Parts
The following spare parts are recommended for use with the NuFlo 2-in. Gas Flowmeter.
Table 3.2—Spare Parts
Part Number Qty. Description
9A-100003517 1 Cartridge, rotor assembly (standard range)
9A-100005113 1 Cartridge, rotor assembly (low range)
9A-100005134 1 Cartridge, roter assembly (high range)
9A-100003518 1 Pickup, magnetic
9A-100062541 2 Centering ring
9A-100005137 1 Pickup adapter extensions (required with 300,
600 and 900 ANSI anges)
9A-100020977 2 Retaining ring
Accessories
The following accessories are available for use with the NuFlo 2-in. Gas Flowmeter. The installation hard-
ware kit includes bolts, nuts, and gaskets for installing the meter in a pipeline.
Table 3.3—Accessories
Part Number Description
9A-100005100 Installation hardware kit, 150 lb ange
9A-100079589 Installation hardware kit, 300 lb ange
9A-100005101 Installation hardware kit, 600 lb ange
9A-100079906 Installation hardware kit, 900 lb ange
9A-50336500100 Flow straightener, line type, 2-in., Sch. 40, 1100L carbon steel
9A-50336500101 Flow straightener, line type, 2-in., Sch. 80, 1100L carbon steel
9A-50336500104 Flow straightener, line type, 2-in., Sch. 40, 1106L 316SS
9A-50336500105 Flow straightener, line type, 2-in., Sch. 80, 1106L 316SS
