Specications
Size 2-in. (50.8 mm)
End Connections Flowmeter installs between two raised face
anges
Working Pressure 0 to 2220 psig (15,306 kPa)
Nominal Calibration Factor
Low Range 325 p/ACF (16600 p/m3)
Standard Range 125 p/ACF (4415 p/m3)
High Range 70 p/ACF (2472 p/m3)
Output Frequency 5 to 320 Hz over rated range
Output Voltage 30 mV peak to peak at 5 Hz, 900 mV peak to peak
at 320 Hz
Pressure Drop Less than 1-in. (24.5 mm) water column at maxi-
mum rated ow
Linearity +/- 2% of reading
Repeatability +/- 0.5% of reading
Temperature 0º to 225ºF (-18º to 107ºC)
Pickup Connector Mates with AN3106A-10SL-4P
Conduit Connection 1-in. (25.4 mm)
Pressure Tap 1/8-in. NPT (3.2 mm)
Compliances CSA Certied Hazardous locations Class I,
Groups A, B, C, D, Div. 1, ANSI 12.27.01-2003
Single Seal
Certied by Cameron in compliance with pre-
qualied materials of NACE MR0175/ISO 15156.
This certication does not imply or warrant the
application of the product in compliance with
NACE MR0175/ISO 15156 service conditions in
which the customer/user installs the product.
