MT4412E Rev.3 15/10/2019 Page 22 of 30
2.5) Programming from a PC
The Multiscan 8+ central unit is fully programmable from a personal computer by means
of special software. The software has been designed for simple and fast programming.
Connection to the PC takes place via the RS232 serial port or USB, available on the main
board of the central unit.
On the central unit board near the RS232 and USB sockets, there is a switch that must
be positioned on the side of the connection to be used (USB or RS232).
The following cables are to be used:
SERIAL CABLE
USB CABLE (printer type)
