Sensitron MULTISCAN 8+ - Multiscan 8; Introduction

MT4412E Rev.3 15/10/2019 Page 5 of 30
1) INTRODUCTION
The highly innovative and versatile MULTISCAN 8+ central units the ideal solution for small
systems with up to 16 gas detectors.
The system provides for the direct connection of 8 detectors to the central unit (4-20mA) and to
additional 8 detectors that can be connected directly to the RS485 bus or via a remote module
with 8 x STG/IN8-S inputs.
Each input can be configured for different types of gas: toxic, refrigerant, flammable, and oxygen,
both for their deficiency and enrichment.
The backlit display offers an accurate indication of gas concentration and allows the display of
established alarm levels.
The central unit manages up to 38 relay outputs, of which 6 are on board the central unit and the
other 32 are via STG/OUT16S and STG/16REL cards.
The central unit is supplied in an ABS housing and can contain 2 x 12Vdc, 7Ah batteries to ensure
that the system works even in the event of a power failure.
The MULTISCAN 8+ is in the process of obtaining SIL1 and ATEX certification pursuant to
EN60079-29-1.
Overview of devices connectable to the MULTISCAN 8+ central unit.
Central unit model
RS485
serial bus
no.
Max no.
detectors
Max no.
outputs
Max number
ST.G/IN8
modules
Max number
ST.G/OUT16
modules
Notes
Multiscan 8+
1
8+8(*)
32+6(*)
1
1
(*) channels and outputs already present in the central unit
Other features of the MULTISCAN 8+, central unit are:
• Event log can be displayed on the screen or downloaded to a PC.
• USB and RS232 serial port for PC connection for programming and control via specific
software.
Central unit ordering codes and accessories
CODE
DESCRIPTION
STMTS/8+
MULTISCAN 8+ gas control panel.
8 Analog 4-20mA inputs and 6 relay outputs on-board the panel.
1 x RS485 type open bus line to connect additional 8 detectors through remote 8-input module
or addressable gas detectors daisy chained to the RS485 bus.
6 relay outputs and additional 16 relays via the dedicated STS/16REL card or via remote
modules.
The panel comes complete with 1 RS232 serial port for PC connection. Housed in ABS box
ACCESSORIES
CODE
DESCRIPTION
STG/IN8S
High safety 8-input remote module with improved performance for MULTISCAN++S1 control panel.
STG/16REL
16-relay card to be connected to MULTISCAN 8+ and STPL4/ESP to provide additional 16 relay
outputs
STG/OUT16S
High safety 16-output remote module (Open collector type) with improved performance.
STG/8REL
Plug and play relay board to be connected to STG/OUT16 to provide 8 relay outputs
STG/MTSS1-
CONF
Windows PC software for MULTISCAN++S1 control panel programming. Running under Windows
XP, VISTA, WIN7, 8, 8.1, 10.
The configuration software is supplied along with the control panel
