UltraWave Product Guide Page 45
a Specifications
General
Power consumption
• @ 12 VDC, 292 mA - transmitter unit 1.1 W, receiver unit 1.95 W,
receiver unit with NIC 2.4 W
• @ 24 VDC, 152 mA - transmitter unit 1.2 W, receiver unit 2.05 W,
receiver unit with NIC 2.45 W
• @ 48 VDC, 84 mA - transmitter unit 1.45 W, receiver unit 2.26 W,
receiver unit with NIC 2.6 W
Operating range • 5 m to 200 m (16.4 ft. to 656 ft.)
Beam width • 20 cm to 8 m (8 in. to 26.24 ft.)
Velocity response • 3 cm/sec to 15 m/sec (1.2 in./sec to 50 ft./sec)
Dimensions
• width - 16 cm (6.25 in.)
• depth - 9 cm (3.375 in.)
• height - 31 cm (12.25 in.)
Mounting post size (OD) • 4.8 to 11.4 cm (1 7/8 to 4 1/2 in.)
Weight • 0.9 kg (2 lbs.) each unit
Transmitter/Receiver
Operating voltage • 12 - 48 VDC
Microwave carrier frequency
• ETSI - 24.150 - 24.250 GHz
• FCC - 24.075 - 24.175 GHz
Separation distance (max.)
• transmitter/receiver - high security 100 m (328 ft.)
• transmitter/receiver - medium security 150 m (492 ft.)
• transmitter/receiver - low security 200 m (656 ft.)
Detection zone length (max.)
• high security 90.5 m (297 ft.)
• transmitter/receiver - medium security 144.2 m (473 ft.)
• transmitter/receiver - low security 200 m (656 ft.)
Antenna pattern
• 13º (horizontal)
• 13º (vertical)
Operating temperature • -40º to +66ºC (-40º to +150º F)
Output relays (2 per unit) • 2 form C relay outputs 30 VDC @ 1 A maximum, non-inductive load
Auxiliary input
(1 per receiver unit)
• Local control mode - self-test input
• Remote control mode - auxiliary device input
