Part No. Description Quantity
1 V3470 Transfer Drive Cap Screw 12
2 V3724 Transfer Drive Cap Washer 12
3 V4005-01 Transfer Drive Cap 1
4 V4029 Transfer Drive Cap O-Ring 2
5 V4015 Transfer Spring 2
6 V4014 Transfer Spring Support 2
7 V4036 Rotor Disc Assembly 2
8 V3105 Distributor O-Ring 1
9 V3180 Tank O-Ring 1
10 V4016 Transfer Seal 6
11 V3031 Valve Body 1
12 V4023 Transfer Drive Shaft Assembly 1
13 V3287 Transfer Drive Shaft Assembly O-Ring 2
14 V4006-01 Transfer Drive Cap Assembly Rear 1
15 V4011-01 Transfer Drive Gear Assembly 1
16 V4012 Transfer Drive Gear Axle 1
17 V4013 Transfer Reduction Gear 1
18 V3264 Transfer Reduction Gear Axle 3
19 V3110 Reducing Gear 12X36 3
20 V3262-01 Reducing Gear Housing Assembly 1
21 V3592 Reducing Gear Housing Assembly Screw 3
22 V4049 Transfer Drive Cap Cover Rear 1
Not Shown V4043 Transfer Drive Motor Assembly 1
Not Shown V4055 Twin Tank Meter Assembly* 1
Not Shown D1400 Second Tank In-Out Head 1
* This water meter should not be used as the primary monitoring device for critical or health effect
applications.
