SENTRY II 930TA Series - Brine Elbow Refill Flow Assembly and Refill Port Plug

28
Drawing
No.
Part No. Description Quantity
1 V3195-01 Refill Port Plug Assembly
Not
normally
used
2 H4615 Brine Elbow Locking Clip 1
3 JCP-P-6 Polytube Insert 3/8” 1
4 JCPG-6PBLK Brine Elbow Nut 3/8” 1
5 V3330-01 Brine Elbow with Flow Control Retainer Assembly 1
6 V3163 Brine Elbow O-Ring 1
7 V3165-01 Brine Flow Control Retainer Assembly (0.5 GPM) 1
Parts Breakdown
Brine Elbow Refill Flow Assembly and Refill Port Plug
Parts Breakdown
