Sentry DCC02 User Manual

Motor Head Unit InstallationMotor Head Unit Installation
LISH
E
N
G
3
With the motor gearbox
disengaged, push the
motor onto the tube until it
is supported on the tube.
Do not yet push it against
the spool wheel.
4
With the motor head unit on
the edge of the steel tube,
align the two drive hooks
on the driving wheel, so that
it will brace against one of
the spokes of the spool
wheel.
17

Sentry DCC02 Specifications

General

Brand	Sentry
Model	DCC02
Category	Garage Door Opener
Language	English
