Advanced FeaturesAdvanced Features
Advanced Features
The DCC02 is equipped with a programmable auto-close timer, which is accessible
via a menu termed the “advanced features menu”. The structure of this menu is
shown as follows:
SET
E
Press and release
SET button
e
x1
ADVANCED FEATURES
MENU
ADVANCED FEATURES
MENU
AUTO-CLOSE OPTION
MENU ITEM
STATUS LED:
1 SHORT FLASH / 2 sec
AUTO-CLOSE TIMER
MENU ITEM
STATUS LED:
2 SHORT FLASH / 2 sec
SET
E
Press and release
SET button
e
x1
TRIGGER
E
Press and release
TRIGGER button
e
x1
Normal
Operation
When the advanced features menu is engaged, all triggers are ignored.
It is not possible to invoke the menus if the door is in motion.
Trigger Exits Menu
