System CommissioningSystem Commissioning
System Commissioning Procedure
This section explains the steps to be followed to commission the DCC02 post fitment
and installation on the door. Commissioning involves powering the system for the first
time, programming the limits, as well as additional electrical connections as may be
required for some applications.
Standard Installation
In most cases, the DCC02 will be installed in a stock-standard configuration without
any ancillary systems attached (beams, status indication extension, external
receiver). If this is the case, you can proceed directly to the section “System Power-
Up”
Enhanced Installation
The DCC02 supports the use of safety beams to prevent injury to persons who are
likely to come into the path of a closing door. The use of a beam also offers peace of
mind when a door is likely to be triggered whilst a vehicle is moved in or out of the
garage.
The use of a beam is MANDATORY when the auto-close feature is enabled!
Failure to install a beam when auto-close is enabled can lead to property
damage and/or injury from a door that starts without warning.
In addition to beams, the DCC02 also supports the use of other remote control
receivers, as may be necessary in some installations (particularly when a
compatibility issue arises and the existing systems cannot be migrated to a SENTRY
remote control product).
Enhanced Installation Detail
The following sections explain electrical and other details pertaining to enhanced
installations
Using an external receiver with the DCC02
The DCC02 accommodates most any type of external receiver and provides a
convenient power source for the receiver, which should be mounted externally to the
wall console. The wall console provides a 24V DC supply for ancillary items, therefore
it is important to ensure that the receiver you intend using, can operate from 24 volts.
Most third-party receivers are able to operate from a 24 volt supply.
The receiver you intend to use, must have a normally-open potential free relay
contact. Receivers that output a “logic level” are not suitable.
