15
14
Function Hydraulic
hood
Compacting
roller or
grader blade
MIDIPIERRE 6-10 l/min /
MIDIPIERRE dt 6-10 l/min 6 -10 /min
2 -3 l/min
MIDISOIL dt 6-10 l/min 6-10 l/min
MULTIFORST 10-14 l/min 25 -35 l/min
STARSOIL 10-14 l/min 25 -35 l/min
SUPERSOIL 10-14 l/min 25 -35 l/min
MAXISOIL 10-14 l/min 70 -95 l/min
Voltage 12V
Fuse 16A
If they do not work in the
described positions, the PTO
shaft and all the transmission
components wear prematurely.
The product warranty becomes
null and void.
Read the PTO shaft
manual!
2) Check movements of the hydraulic functions and
if necessary adjust at the following flow rates:
b. WITH ADAM™ alignment system
1) Connect a pair of hydraulic pipes marked with
the same colour to the tractor inlets by means of
quick couplings.
4.2.4 Connection of hydraulic quick couplings
for auxiliary functions
same colour
=
=
≠
If the tractor does not have a suitable socket,
connect the wires to another electricity source
according to the following indications.
On some models, the cooling system of the
transmission is electric.
4.2.5 Connection of electrical sockets
Position the control panel in the cab and fix it
properly.
Connect the three-pole electrical power connec-
tor to the tractor's socket.
not connected
