Congratulations on your choice! For over 75 years the
goal of SEPPI M. S.p.A. has been to guarantee high
quality products which will have a long working life,
and manufacture them to meet customers' require-
ments.
In manufacturing its machines, SEPPI M. S.p.A.
uses the best materials and technology. However, to
make the most of the designers’ best efforts to make
functional, reliable machines with valid safety devices,
you must read carefully the instructions in this user’s
manual and in the safety instructions (an integral part
of the manual). When the machine is treated and kept
with care, it limits all types of problems and saves you
time and money.
In case this information is insufficient, our staff and
your dealer will always be available for any further
clarification.
PLEASE CAREFULLY READ THE PRESENT MANU-
AL, THE USER'S MANUAL OF THE PTO SHAFT AND
RULES FOR THE USE OF
SHAFT CONES.
THE PRESENT MANUAL MUST BE KEPT TOGETHER
WITH THE USER'S MANUAL OF THE PTO SHAFT AND
THE RULES FOR THE USE OF SHAFT CONES.
- EC declaration of conformity
- Use and maintenance manual of PTO shaft
(if supplied upon request)
- Rules for the use of shaft cones
- Spare parts list
- Technical commercial documentation
This manual contains all functional, technical char-
acteristics and performance features for the machine
regarding it’s “intended – expected use”. It also con-
tains all operating and maintenance instructions. This
manual has been written for:
- operators responsible for transport and handling
- operators using the machine
- maintenance personnel.
A person must be responsible for keeping the doc-
umentation provided with the machine in a suitable
place so that it is always in good condition and availa-
ble for consultation.
If this manual is lost or deteriorated, request a
replacement copy from the manufacturer; always indi-
cate the serial number (indicated in the manual) when
making your request.
NOTE: the manufacturer must be promptly notified of
any changes to the site of destination and/or owner-
ship or location of the machine
.
1. PRELIMINARY INFORMATION
1.1 Symbols: meaning and use 4
1.2 Collaboration with the user 4
1.3 Compliance with standards 4
1.4 Manufacturer's responsibility and warranty 4
2. SAFETY AND ACCIDENT PREVENTION
2.1 Operator qualification 5
2.2
Introduction to safety at work
5
2.3 Safety rules and residual risks 5
2.4 Stickers and safety labelling 9
3. TECHNICAL INFORMATION
3.1 Intended use 10
3.2 Models 10
3.3 Safety devices 11
3.4 Technical data
4. HANDLING AND COMMISSIONING
4.1 Handling, lifting and unloading 12
4.2 Commissioning 12
4.3 Adjustments 15
5. OPERATION AND USE
5.1 Checks prior to work 16
5.2 Tractor selection 16
5.3 Starting the cooling system 17
5.4 Start-up and processing 17
5.5 Safety distances 18
6. MAINTENANCE
6.1 Belt tension check and adjustment 18
6.2 Lubrication 19
6.3 Oil leaks 20
6.4 Safety devices and information 20
6.5 Replacing tools 20
6.6 Replacing anti-wear frame 22
6.7 Checking screws 22
6.8 Troubleshooting 22
6.9 Disabling 23
7 SPARE PARTS 23
8 CONTROL REGISTER 23
9 DISMANTLING, SCRAPPING AND WASTE
DISPOSAL
23
“CE” marking: affixed to machine structure
To fill out upon delivery of the machine:
Manufacturer: SEPPI M. S.p.A.
Zona Artigianale 1
39052 CALDARO (BZ) –
ITALY
Manual code: Stone crusher Rev 2 of
1.09.2014
Machine:
Model:
Serial number:
Year of manufacture:
To Next Page
