Only work with the hood open
when absolutely necessary!
The grader blade has the following functions:
1) Compacting the soil
2) Evenly distributing the material
3) Levelling the soil
- Lift the grader blade when transporting the
machine.
- Lower the blade during use.
- Push the blade down to increase compacting
pressure (indicated on the pressure gauge).
- Adjust inclination of the blade to move material
to the right or left.
- When the machine is parked, the grader blade
must rest on the ground.
4.3.5 Adjusting grader blade
Brown +12V
Blue GND
1) Check the features of the hydraulic motors and
valve blocks in the attached guide, if the machine
is supplied with them.
2) Follow the installation and commissioning in-
structions in the attached guide.
4.2.6 Connecting a hydraulically driven
machine
Connecting wires:
If the machine is equipped with one or more sup-
port stands, they must be closed during work.
1) Open the hood to expose the rotor, to fell trees
and to reduce power output
2) Close the hood to improve the degree of mulch-
ing
4.2.7 Support stand
4.3.2 Adjusting hydraulic hood
1) See points 4.2.1
4.3 Adjustments
4.3.1 Adjusting 3-point-linkage
manually or hydraulic
If the machine has support skids or adjustable
conveying skids, proceed as follows:
1) Lift the skids to bring the rotor close to the
ground
2) Lower the skids to move the rotor away from the
ground
The roller has the following functions:
1) Levelling the machine
2) Compacting the soil
3) Guard frame to push trees and shrubs
4.3.3 Adjusting support skids
4.3.4 Adjusting compacting roller
Some models are supplied with
non-adjustable anti-wear skids
as standard.
BAR PSI
BAR PSI
