Serfas E DASH PLUS 500W - Display and Control Specifications

DISPLAY / CONTROL SPECIFICATIONS
• 48 Volt Power Supply (500W)
• Current Rated: 10mA
• Maximum Operating Current: 30mA
• Power O Leakage Current < 1uA
• Operating Current to Controller: 50mA
• Operating Temperature: -20º to 45ºC
• Storage Temperature: -20º to 50ºC
• Waterproof Rating: IP65
• Bearing Humidity: 30% - 70% RH
Figure 2
SERFAS E-BIKE
Figure 1
POWER SWITCH
____
Figure 3
CHARGING PORT
CONTROL & DISPLAY
Model: DP C18.CAN BUS
___
Up
Light On/O
OK/Enter
System
On/O
Down
