GETTING STARTED
2
SERFAS E-BIKE OWNER’S MANUAL
The Dash Plus 500W is operated using the control pad on the
handlebars. The control pad is located near the left-hand brake lever.
Push the power button on the battery to turn on. The current charge
level will temporarily display on the LEDs (4=full, 1=near empty), then
one green LED to show the battery is turned on. Press and hold the
button, 2 seconds, on the handlebar controls to turn system on. Display
should light up. Now, your e-bike is ready to ride. To turn o, press and
hold for 2 seconds. The battery will automatically turn o. Automat-
ic system shutdown time is set to 5 minutes by default.
The Dash Plus 500W bike oers pedal assist. When using pedal assist,
an electric motor supplements the rider’s own eort. To use the pedal
assist, simply start pedaling, then push the button to increase
assist or button to decrease pedal assist. 0 = lowest, 5 = highest.
Pedal assist will engage at speeds up to 28 MPH.
The Dash Plus 500W e-bike is equipped with a throttle, which is
mounted near the rider’s left thumb, to propel the bike without
pedaling. To use the throttle, start pedaling (one pedal revolution)
then push down on the throttle while pedaling. Once the bike is
moving on throttle power, you can stop pedaling entirely and use
your thumb to control the speed of the bike. The throttle can propel
you at speeds up to 20 MPH.
THE MOTOR STOPS WHEN YOU:
1) Stop pedaling 2) Squeeze the brake levers 3) Release the throttle.
Simply begin pedaling again to re-engage the motor.
