Outlet State/Control State Descriptions
The following table shows the differences between outlet state and control state
• The outlet state is the current operating state of the outlet.
• The control state is the last user-issued control action on the outlet.
Outlet State
Control State
Description
On
On
Outlet is on.
Off
Off
Outlet is off.
Off
Pend On
Outlet is off and about to turn on in response to a sequence timer.
Off
Reboot
Outlet is off and a Reboot action has been initiated.
On
Idle On
A restart has occurred – last control state has been maintained.
On
Idle Off
A restart has occurred – last control state has been maintained.
On
Wake On
A power-loss has occurred – wakeup state has been applied.
Off
Wake Off
A power-loss has occurred – wakeup state has been applied.
On/Wait
Off
Outlet state in transition – re-query of outlet status required.
Off/Wait
On
Outlet state in transition – re-query of outlet status required.
On/Error
(varies)
Error state – outlet should be off but current is sensed at the outlet.
Off/Error
(varies)
Error state – outlet should be on but no current is sensed at the outlet.
Off/Fuse
On
Outlet should be on but a blown fuse has been detected.
On/Fuse
On
Outlet should be on but a blown fuse has been detected downstream
No Comm
(varies)
Communication to the outlet has been lost – control state will be
applied when communication is re-established.
