2 Setra Super Count
TM
Operator's Manual
FIGURE 1. Components and features of the Setra Super Count.
Adjustable Foot
Level Bubble
Keypad
Display
Weighing Platform
Rectangular weighing platform shown is
used on scales of 27 pound capacity
or more.
Weighing Platform
Display
Keypad
Level Bubble
Adjustable Foot
Round weighing platform shown is
used on scales of 5000 gram
capacity or less.
Adjustable Foot
RS-232C
Interface
Connector
DC Connector
Battery
On/Off Switch
(Optional)
Battery Door
Remote Scale
Connector
(Optional)
