Service
Description of status and operating displays
Operating Instructions – MOVIMOT
®
flexible
203
"F-RUN" LED
LED Meaning
Off
• Device off.
• No MOVISAFE
®
CSB51A safety option available.
Flashing sequence Device identification for safety key ID query.
Green
Steady light
Device in operating state and parameter set approved.
Green
Flashing slowly
Acceptance of the module has not yet taken place.
Green
Flashing quickly
• Device booting up or initializing
• Device in parameterization state
Yellow
Flashing slowly
Device in the operating state with one or more of the following constraints:
• Module controls the inverter.
• Test mode
Yellow
Steady light
STO drive safety function is active.
Red
Flashing slowly
Device identification for parameterization
Red
Flashing quickly
Firmware update, do not switch the device off.
Red
Steady light
Critical fault, cannot be acknowledged.
29128668/EN – 12/2019
