8
Service
Description of status and operating displays
Operating Instructions – MOVIMOT
®
flexible
206
LED Operating status/ Meaning Measure
Fault
code
Subfault code
Red
Steady light
1 1, 2 Output stage monitoring fault Contact
SEW‑EURODRIVE
Service.
4 2 Brake chopper fault
7 2 DC link fault
9 3, 4, 8 Control mode fault
10 2, 99 Data Flexibility fault
11 7, 8 Temperature monitoring fault
13 1, 3, 6, 7, 8, 9, 11,
13, 15, 22, 23
Encoder 1 fault
16 2, 11, 12. 30 Startup fault
17 7 Internal processor fault
18 1, 3,4, 7, 8, 9, 10,
12, 13
Software error
20 1.7 Device monitoring fault
21 1 S-Drive 1 fault
23 5, 6, 7, 8 Power section fault
25 10, 12–19, 50, 51,
81
Parameter memory monitoring
28 13 FCB drive function fault
33 1, 2, 6, 7, 8, 10 System initialization fault
46 1 Safety card fault
LEDs "L/A" IN
LED Meaning
Green
Illuminated
No Ethernet connection with the EtherCAT
®
/SBus
PLUS
interface IN.
Yellow
Illuminated
An Ethernet connection is present between an EtherCAT
®
/SBus
PLUS
interface IN and
another Ethernet station.
LEDs "L/A" OUT
LED Meaning
Green
Illuminated
No Ethernet connection with EtherCAT
®
/SBus
PLUS
OUT.
Yellow
Illuminated
An Ethernet connection is present between EtherCAT
®
/SBus
PLUS
OUT and another
Ethernet station.
29128668/EN – 12/2019
