8
Service
Description of status and operating displays
Operating Instructions – MOVIMOT
®
flexible
207
8.5.3 Bus-specific LEDs for EtherCAT
®
/SBus
Plus
"RUN" LED
LED Meaning
Off "INIT" state
The interface is in "INIT" state.
Green
Flashing
"PRE_OPERATIONAL" state
Mailbox communication is possible.
Process data communication is not possible.
Green
Flashing once
"SAFE_OPERATIONAL" state
Mailbox and process data communication is possible.
Safety-related output signals are not output.
Green
Illuminated
"OPERATIONAL Mode" state (operational)
Mailbox and process data communication is possible.
"ERR" LED
LED Meaning
Off No error
The interface is in operating state.
Red
Flickering
Boot error
A BOOT error has occurred.
"INIT" state has not been reached.
However the "Change" parameter is set to "0x01:change/error".
Red
Flashing
Invalid configuration
A general configuration error has occurred.
Red
Flashing once
Unprompted state change
The slave application has changed the state automatically.
The "Change" parameter is set to "0x01:change/error".
Red
Flashing twice
Application watchdog timeout
A watchdog timeout error has occurred in the application.
Red
Illuminated
PDI
1)
Watchdog Timeout
A PDI watchdog timeout error has occurred.
1) PDI = Process Data Interface
29128668/EN – 12/2019
