8
Service
Device replacement
Operating Instructions – MOVIMOT
®
flexible
322
4. Compare the type designation of the memory module.
INFORMATION
The new memory module must have the same type designation as the old memory
module.
5. Set the DIP switches on the new memory module in the same way as the control
elements of the previous memory module.
6. Insert the new memory module in the new electronics cover.
7. Place the electronics cover onto the connection box and screw it on.
8. Supply the device with voltage.
9. Check the startup of the device.
ð If required, perform startup again or load the saved startup to the device.
ð For devices with safety card, check the startup of the safety card. For more in-
formation, refer to the "MOVISAFE
®
CSB51A Safety Option" manual.
10. Check the new electronics cover for proper functioning.
29128668/EN – 12/2019
