Sewha SI 410 - Weighing mode 6. - Accumulation mode 1.

- 37 -
◆ Weighing mode 6. – Accumulation mode 1. (500-06)
-Each set point need to be the difference between each steps.
Time
Time
Contents
t1
Finish Relay Output Delay Time (Function 510)
When Function 102-3 or 102-6, save the date after t1 time.
t2
Finish Relay Output Time (Function 520)
Relay output
Relay
Condition
Relay
Condition
OUT 1
Current weight ≥ SP1 (ON)
Current weight < SP1 (OFF)
OUT 4
Current weight ≥ SP1+SP2+SP3+SP4 (ON)
Current weight < SP1+SP2+SP3+SP4 (OFF)
OUT 2
Current weight ≥ SP1+SP2 (ON)
Current weight < SP1+SP2 (OFF)
OUT 5
After SP1+SP2+SP3+SP4
After t1 set time
During t2 set time (ON)
OUT 3
Current weight ≥ SP1+SP2+SP3 (ON)
Current weight < SP1+SP2+ SP3 (OFF)
OUT 6
Within near zero range
(Function HF29) (ON)
