Example :
If you attempt to transmit ESC 3
n
to the printer, but DTR (DSR for
the host computer) goes to MARK before
n
is transmitted and then
DLE EOT 3 interrupts before
n
is received, the code <10> H for DLE
EOT 3 is processed as the code for ESC 3 <10>H.
n
= 1: Printer status
Bit Off/On Hex Decimal Function
0 Off 00 0 Not used. Fixed to Off
1 On 02 2 Not used. Fixed to On
Off 00 0 Drawer open/close signal is LOW (connector pin 3). 2
On 04 4 Drawer open/close signal is HIGH (connector pin 3).
Off 00 0 On-line 3
On 08 8 Off-line.
4 On 10 16 Not used. Fixed to On
5,6 - - - Undefined.
7 Off 00 0 Not used. Fixed to Off.
n
= 2: Off-line status
Bit Off/On Hex Decimal Function
0 Off 00 0 Not used. Fixed to Off
1 On 02 2 Not used. Fixed to On
Off 00 0 Cover is closed 2
On 04 4 Cover is open
Off 00 0 Paper is not being fed by using the FEED button 3
On 08 8 Paper is being fed by the FEED button
4 On 10 16 Not used. Fixed to On
Off 00 0 No paper-end stop 5
On 20 32 Printing is being stopped
Off 00 0 No error 6
On 40 64 Error occurs
7 Off 00 0 Not used. Fixed to Off
Bit 5: Becomes on when the paper end sensor detects paper end and printing stops.
n
= 3: Error status
Bit Off/On Hex Decimal Function
0 Off 00 0 Not used. Fixed to Off
1 On 02 2 Not used. Fixed to On
2 - - - Undefined
Off 00 0 No auto-cutter error 3
On 08 8 Auto-cutter error occurs
4 On 10 16 Not used. Fixed to On
Off 00 0 No unrecoverable error 5
On 20 32 Unrecoverable error occurs
Off 00 0 No auto-recoverable error 6
On 40 64 Auto recoverable error occurs
7 Off 00 0 Not used. Fixed to Off
Bit 3: If these errors occur due to paper jams or the like, it is possible to recover by
TITLE : WTP-150
Page -24 -
