When CODE93 (m=72) is used :
·The printer prints an HRI character (□)as start character at the
beginning of the HRI character string.
·The printer prints an HRI character(□)as a stop character at the end of
the HRI character string.
·The printer HRI characters (■+an alphabetic character) as a control
character(<00>H to <1F>H and <7F>H):
Control character Control character
ASCⅡ Hex Decimal
HRI character
ASCⅡ Hex Decimal
HRI
character
NUL 00 0 ■U DLE 10 16 ■P
SOH 01 1 ■ A DC1 11 17 ■Q
STX 02 2 ■ B DC2 12 18 ■R
ETX 03 3 ■C DC3 13 19 ■S
EOT 04 4 ■ D DC4 14 20 ■T
ENQ 05 5 ■E NAK 15 21 ■U
ACK 06 6 ■F SYN 16 22 ■ V
BEL 07 7 ■G ETB 17 23 ■W
BS 08 8 ■H CAN 18 24 ■X
HT 09 9 ■I EM 19 25 ■ Y
LF 0A 10 ■ J SUB 1A 26 ■ Z
VT 0B 11 ■ K ESC 1B 27 ■A
FF 0C 12 ■L FS 1C 28 ■B
CR 0D 13 ■M GS 1D 29 ■ C
SO 0E 14 ■ N RS 1E 30 ■ D
SI 0F 15 ■ 0 US 1F 31 ■ E
DEL 7F 127 ■T
[Example] Printing GS k 72 7 67 111 100 101 13 57 51
When CODE 128 (m = 73) is used:
·Refer to Appendix J for the information of the CODE 128 bar code and
is
code table.
·When using the CODE 128 in this printer, take the following points into
account for data transmission:
①
The top of the bar code data string must be code set selection
character (any of CODE A, CODE B or CODE C) which selects the
first code set.
②
Special characters are defined by combining two characters
