Shark 100 User Manual

Doc# E145701 D - 7
D: DNP 3.0 Protocol Assignments
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
D.4.1.3: 32-Bit Binary Counter Without Flag (Obj. 20, Var. 5)
Counters support the following functions:
Read (Function 1)
A READ request for Variation 0 is responded to with Variation 5.
Counters are used to communicate the following data measured by Shark® 100
meters:
Hour Readings
Hour Readings (Points 0 - 4)
NOTE: These readings may be cleared by using the Control Relay Output Block (see
previous Section D.4.1.2).
D.4.1.4: 16-Bit Analog Input Without Flag (Obj. 30, Var. 4)
Analog Inputs support the following functions:
Read (Function 1)
A READ request for Variation 0 is responded to with Variation 4.
Analog Inputs are used to communicate the following data measured by Shark® 100
meters:
• Health Check
• Phase-to-Neutral Voltage
• Phase-to-Phase Voltage
Point Readings Unit
0 +W hour Wh
1-W hourWh
2 +VAR hour VARh
3-VAR hourVARh
4 +VA hour VAh
