Doc# E145701 5 - 12
5: Communication Installation
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
The configuration parameters can be changed at any time and are retained when the
meter is not powered up. After the configuration has been changed and saved, the
Ethernet card performs a reset.
Only one person at a time should be logged into the network port used for setting up
the meter. This eliminates the possibility of several people trying to configure the
Ethernet interface simultaneously.
It is possible to reset the Ethernet card to its default values. Follow the procedure in
Section 5.2.2.2.
5.2.2.1: Configuring the Shark® 100 - INP10 Meter's Ethernet Con-
nection on the Host Computer
Establish a Telnet connection on port 9999. Follow these steps:
1. From the Windows Start menu, click Run and type 'cmd'.
2. Click the OK button to bring up the Windows' Command Prompt window.
3. In the Command Prompt window, type: “telnet 10.0.0.1 9999" and press the Enter
key.
NOTE: Make sure there is a space between the IP address and 9999.
When the Telnet connection is established you will see a message similar to the
example shown below.
4. To proceed to Setup Mode press Enter again. You will see a screen similar to the
one shown on the next page.
Serial Number 5415404 MAC Address 00:20:4A:54:3C:2C
Software Version V01.2 (000719)
Press Enter to go into Setup Mode
