Shark HE Series User Manual

96-723, 97-715, 97-716, 97-717 • REV. 2/04
13
PRESSURE WASHER
OPERATOR’S MANUAL
EXPLODED VIEW PARTS LIST
ITEM PART # DESCRIPTION QTY
1 6-01062 GFCI, 120V, 15 Amp w/36' 12-3
Cord (201006D, 201007D,
211026D) 1
6-01060 GFCI, 120V 20 Amp w/36' 12-3
Cord (201406D, 201507D) 1
2 6-03911 Lid, Plastic Carlon
(201406D, 201507D) 1
3 6-020204 Switch, 2 Pos. 120V-600V
(201406D, 201507D) 1
4 6-03910 Box, Plastic Carlon
(201406D, 201507D) 1
11-1042 ▲ Label, Ground 1
5 6-051595 Strain Relief, STRT, LQ Tite
Large (201406D, 201507D) 1
6-05172 ▲ Locknut, 3/4" 1
6 6-0104 Cord, Service, SOWA, 12/3
(201406D, 201507D) 2 ft.
7 90-1991 Screw, 10/32" x 1/2" BHSOC
(201406D, 201507D) 6
8 90-017 Nut, 10/32" Keps
(201406D, 201507D) 9
9 90-100030 Screw, 10-32" x 3/4" RH, SL,
BLK (201406D, 201507D) 1
10 95-07111118 Switch Box BRKT
(201406D, 201507D) 1
11 5-1046 Motor, 1.5 HP, 1 PH, 3450 RPM,
C-Face (201006D, 2-11026D,
201007D) 1
6-05152 ▲ Strain Relief, STRT, LQ TITE 3
(201006D, 201007D) 1
6-05181A ▲ Locknut, 1/2" (201006D,
201007D) 1
5-1047 Motor, 2 HP, 1 PH, 3450 RPM,
(201406D, 201407D) 1
6-0517 ▲ Strain Relief, 3/4"
(201406D, 201407D) 1
12 6-02049 Switch, Toggle, Assy (201006D,
201007D, 2-11026D) 1
13 90-2001 Nut, 5/16" ESNA, NC 8
14 90-4001 Washer, 5/16" Flat SAE 12
15 11-0350F Label, French Warning 1
16 11-0314 Label, Instr. (TE Models) 1
11-0311 Label, Instr. (HE Models) 1
10-99073 Label, Instr. (ZE Models) 1
11-0325 Label, Instr. (ET Models) 1
17 95-07200126 Handle Assy, Red (TE, HE,
ET Models) 1
95-07102116 Handle Assy, Black (Model
ZE) 1
18 4-16540 Nozzle, Compl. QCEM-6540
w/Blk Nylon (Soap Nozzle) 1
ITEM PART # DESCRIPTION QTY
19 4-12804015 Nozzle, SAQCMEG 1504
Yellow (201006D, 201007D,
2-11026D) 1
4-12803015 Nozzle, SAQCMEG 1503 Yellow
(201406D, 201507D) 1
20 2-0103 Grommet, Rubber, Nozzle
Holder 2
21 90-1006 Bolt, 5/16" x 3/4" NC 4
22 10-08021 Label, Disconnect Power 1
23 10-08018 Label, Warning, Service
Cord 1
24 6-05154 Strain Relief 90° (201406D) 1
6-05181 ▲ Locknut, 1/2" Conduit
(201406D) 1
25 2-01023 Mount, Vibration, 5/16”-18 x
9/16” Stud, 30 Duro 4
26 10-08016 Label, Intended For Indoor
Use 1
27 10-9999 Label, Clear Lexan,
2-1/4" x 4-1/2" 1
28 2-300816 Pump Protector, 3/8" PTP 1
29 2-2006 Nipple, 3/8" x 3/8" NPT ST
Female 1
30 2-10943 Swivel, 3/8" MP x 3/4" (201001D,
201501D, 301001D) 1
31 90-4002 Washer, 3/8" Flat SAE 4
32 90-1016 Bolt, 3/8" x 1", NC 4
33 5-2107 Pump, Comet AXD2020E
(201006D, 201406D,
2-11026D) 1
5-1618 Pump, Legacy, WMH2521
(201007D, 201507D) 1
34 2-9040 Clamp, Hose UNI .46 - .54 2
35 4-02080000 Hose, 1/4” x 1/2” Clear
Vinyl 4 ft.
36 2-1904 Strainer, 1/4” Barb 1
