GETTING TO KNOW YOUR SHARK MATRIX
™
PLUS 2-IN-1 ROBOT
CLEAN Button
LIDAR Navigation
Module
Front Bumper
Error Indicator Light
Charge Indicator Lights
Wi-Fi Indicator Light
Charging Contact
Battery Door
Cli Sensors
Brushroll Door
Drive Wheel
Self-Empty Dust
Bin and Filter
Front Caster
Wheel
Brushroll
GETTING TO KNOW YOUR SHARK MATRIX
™
PLUS 2-IN-1 ROBOT
SELF-EMPTY BASE
FRONT
ROBOT DUST BIN
LANDING MAT
(This side up)
Charging Contacts
Charger Cord
Post-Motor
Filter Door
Pre-Motor
Filter Housing
Release Button
VAC & MOP 2-in-1 Dust Bin
Holds dry debris for vacuuming and water for mopping
Fill Port
Pad Plate
DOCK Button
Filter
Release
Button
SELF-EMPTY BASE
BACK
Base Dust Bin
Cli Sensors
Mopping Pad
Long Single
Side Brush
Note: Side brush design
may vary
Indicator Light
Holds mopping pad and enables
mopping mode when attached to
the robot dust bin
Cli Sensors
