155
27DV-S100
27DV-CS10
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual: electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does not have the same safety characteristics as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free;
1-800-BE-SHARP
Ref. No. Part No. ★ Description Code
PICTURE TUBE
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
' MARK : X-RAY RELATED PARTS
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques sp
éleciales de s élecurit éle, sont identifi élees dans ce manuel : les pi`eces
élelectriques qui pr élesentent ces particularit éles, sont rep éler élee
par la marque å et sont hachur élees dans les listes de pi‘eces et dans
les diagrammes sch élematiques.
La substitution d’une pi`ece de rechange par une autre qui ne pr éLesente
pas les m éoemes caract éLeristiques de s élecurit éle que la pi`ece
recommand élee parl`usine et dans ce manuel de service, peut provoquer
une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
★ MARK : SPARE PARTS-DELIVERY SECTION
★ MARQUE: SECTION LIVRAISON DES PIECES DERECHANGE
' MARQUE: PIECES RELATIVE AUX RAYONS X
'å VB68LUW696X~S J Picture Tube CV
å RCiLH0259PEZZ R Deflection Yoke BN
LHLDW0003PEKZ R ADG Coil Holder, x4 AB
LHLDW1075PEKZ R Holder AC
PMAGF3040CEN1 J Purity Magnet AN
PMAGG3006CEZZ J Magnet AC
PSPAG0003PEZZ J Spacer, x3 AD
QCNW-5298CEZZ J Connecting Cord (PU) AE
QEARC2913PEZZ R Grounding Strap AK
å RCiLG0056PEZZ R Degaussing Coil AS
RCORF0031CEZZ J Ferrite Core AM
DUNTKA603WEV5 – Main Unit(27DV-S100) —
DUNTKA603WEV6 – Main Unit(27DV-CS10) —
DUNTKA637WEV1 – DVD/VCR Power Unit —
DUNTKA638WEV1 – Deflection Unit —
DUNTKA639WEV1 – TV Power Unit —
DUNTKA640WEV1 – Terminal Unit —
DUNTKA642WEV1 – Control(DVD) Unit —
DUNTKA643WEV1 – Control(VCR) Unit —
DUNTKA669WEV1 – Front AV Unit —
DUNTKA680WEV1 – Terminal Sub Unit —
DUNTKA686WEV1 – CRT Unit —
DUNTK6054TE6H – DVD Main Unit —
DUNTK6081TEV1 – DVD Sub Unit —
B3DVK03DVD – DVD Unit —
Ref. No. Part No. ★ Description Code
DUNTKA603WEV5(27DV-S100)
DUNTKA603WEV6(27DV-CS10)
MAIN Unit
INTEGRATED CIRCUITS
IC2001 RH-iX1731GEZZQ R MN101D06GSJ AZ
IC2002 VHiPST600H/-1 J IC-ST600H-2 AE
IC2003 VHiBR24C04F-1 J BR24C04F-WE2 AG
IC2004 VHiBR24C08F-1 J BR24C08F-E2 AF
(27DV-S100)
IC2005 VHiPST994C/-1 J PST994C AD
IC2201 VHiHA8317NF-1 J HA118317NF AZ
or
VHiHA8317F/-1
IC6651 VHiAN3651FB-1 J AN3651FBP AU
IC7006 VHiLB11880+-1 J LB11880 AL
or
VHiLB1988//-1
TRANSISTORS
Q2001 VS2SC1623L51E J 2SC1635L5 AB
Q2002 VS2SA1271-Y-1 J 2SA1271-Y AB
Q2003 VS2SA1271-Y-1 J 2SA1271-Y AB
Q2004 VS2SC1623L51E J 2SC1635L5 AB
Q2201 VS2SC1623L51E J 2SC1635L5 AB
Q3302 VS2SD1306-E-1 J 2SD1306-E AC
Q3306 VS2SA812-M/1E J 2SA812-M AC
Q5501 VS2SC1623L51E J 2SC1635L5 AB
Q5502 VS2SC1623L51E J 2SC1635L5 AB
Q6602 VS2SC3203Y/-1 J 2SC3023Y AB
Q6603 VS2SC1623L51E J 2SC1635L5 AB
Q6604 VSKRC104S//-1 J KRC104S AA
Q6605 VS2SC2712Y/-1 J 2SC2712Y AB
Q6606 VS2SC2712Y/-1 J 2SC2712Y AB
Q6607 VSKRA102S//-1 J KRA102S AA
Q6608 VSKRC104S//-1 J KRC104S AA
Q6609 VSKRC104S//-1 J KRC104S AA
Q6651 VS2SD1306-E-1 J 2SD1306-E AC
Q6652 VS2SD1306-E-1 J 2SD1306-E AC
Q6653 VSKRA104S//-1 J KRC104S AA
Q6654 VSKRC104S//-1 J KRC104S AA
Q7001 RH-PX0233GEZZ J PT493FL2, Strat Sensor AD
Q7002 RH-PX0233GEZZ J PT493FL2, End Sensor AD
Q7010 VS2SC1623L51E J 2SC1635L5 AB
Q7011 VS2SC1623L51E J 2SC1635L5 AB
Q7020 VS2SC1623L51E J 2SC1635L5 AB
