Sharp 27DV-S100 User Manual

18
27DV-S100
27DV-CS10
ITEM OSD DISPLAY INITIAL RANGE SETTING DATA
SUB COTRAST(*1) PICTURE 20 00 - 31 Adjustment is required of each set.
TINT (*1) TINT 30 00 - 47 Adjustment is required of each set.
SUB COLOR (*1) COLOR 18 00 - 31 Adjustment is required of each set.
BRIGHTNESS (*1) BRIGHT 55 00 - 95 Adjustment is required of each set.
SHARPNESS SHARP 15 00 - 47 Fix at "8"
V-POSITION (*1) V POSITION 95 00-127 Adjustment is required of each set.
H-POSITION (*1) H POSITION 17 00 - 31 Adjustment is required of each set.
R CUT-OFF (*1) R CUT-OFF 64 00-255 Adjustment is required of each set.
G CUT-OFF (*1) G CUT-OFF 64 00-255 Adjustment is required of each set.
B CUT-OFF (*1) B CUT-OFF 64 00-255 Adjustment is required of each set.
G GAIN (*1) G GAIN 64 00-127 Adjustment is required of each set.
B GAIN (*1) B GAIN 64 00-127 Adjustment is required of each set.
Y- γ CURVE Y-γ CURVE 00 00 - 03 Fix at "03"
VSM PHASE VSM PHASE 01 00 - 03 Fix at "02"
APACON PEAK f0 APA PEAK f0 01 00 - 07 Fix at "01"
DC RESTRATION RATE DC REST 21 00 - 63 Fix at "07"
DC RESTRATION LIMIT DC REST LMT 00 00 - 03 Fix at "02"
BLACK STRETCH POINT BLK STRETCH 03 00 - 07 Fix at "00"
APL VS BPS APL VS BPS 01 00 - 03 Fix at "01"
B.L.C B.L.C 01 00 - 01 Fix at "00"
DYNAMIC ABL POINT DY ABL POINT 04 00 - 07 Fix at "06"
DYNAMIC ABL GAIN DY ABL GAIN 04 00 - 07 Fix at "03"
ABL POINT ABL POINT 03 00 - 07 Fix at "07"
ABL GAIN ABL GAIN 03 00 - 07 Fix at "04"
Y-DL Y-DL 01 00 - 01 Fix at "01"
TOF-Q TOF-Q 04 00 - 07 Fix at "04"
VSM GAIN VSM GAIN 01 00 - 03 Fix at "02"
OSD SL OSD SL 00 00 - 01 Fix at "00"
C-DECODE C-DECODE 161 00-255 Fix at "153"
DVD BR-OFF DVD BR-OFF 30 30 - 70 Fix at "50"
PICTURE HEIGHT V AMP 22 00-127 Adjustment is required of each set.
V-LINEARITY V-LINEARITY 22 00 - 31 Adjustment is required of each set.
V-S CORRECTION V-S CORRECT 40 00 - 63 Fix at "47"
PICTURE WIDTH H AMP 30 00 - 63 Adjustment is required of each set.
E-W PARABOLA E-W PARABOLA 19 00 - 63 Adjustment is required of each set.
E-W CORNER E-W CORNER 18 00 - 31 Adjustment is required of each set.
TRAPEZIUM TRAPEZIUM 55 00-127 Adjustment is required of each set.
AGC AGC 01 00 - 01 Fix at "01"
Y-MUTE MUTE 00 00 - 02 00=NORMAL, 01=NO-Y, 02=NO-VERTICAL
ENERGY SAVE ENERGY SAVE 21 00 - 63 Fix at "21"
TEXT BOX TEXT BOX 8 00 - 31 Adjustment is required of each set.
TEXT PICTURE TEXT PICTURE 20 00 - 80 Fix at "20"
CCD LEVEL CCD LEVEL 04 00 - 20 Fix at "10"
OPTION (VCR) OPTION (VCR) 39 00-255 Fix at "39"
OPTION (TV) OPTION (TV) 31 00-127 Fix at "127"
MTS INPUT LEVEL INPUT LEVEL 07 00 - 15 Adjustment is required of each set.
MTS VCO MTS VCO 37 00 - 63 Adjustment is required of each set.
MTS FILTER FILTER 30 00 - 63 Adjustment is required of each set.
WIDE BAND DETECT WIDE BAND 35 00 - 63 Adjustment is required of each set.
SPECTRAL DETECT SPECTRAL 22 00 - 63 Adjustment is required of each set.
H COMP H COMP 03 00 - 07 Fix at "03"
V COMP V COMP 03 00 - 07 Fix at "03"
CCD POSITION CCD POSITION 38 00 - 63 Fix at "38"
(*1) Set the adjustment value to tuner input instead of the adjustment at DVD input (play).
Table-A
PART ADJUSTMENT
NOTE
REPLACED NECESSARY UNNECESSARY
IC2001 X Data is stored in IC2003.
IC401 X
The adjustment is needed to compensate for characteristics
of parts including IC401.
IC2003 X
Initial setting values are written from IC2001. Adjust for best
results.
CRT X Adjust items related to picture tube only.
Table-B
