24
27D
V
-S100
27D
V
-CS10
FUNCTION OF MAJOR MECHANICAL P
ARTS (BO
TT
OM
VIEW)
26
24
21
22
19
20
12
23
No.
Function
No.
Function
12
Casecon drive gear
19
Slow brake
20
Master cam
21
Capstan D.D. motor
22
Reel belt
23
Clutch lever
24
Limiter pulley ass'y
26
Shifter
23
25
Table of Contents
Table of Contents
1
Important Service Safety Precation
2
Safety Notice
3
Safety Precautions
6
Electrical Specifications
7
Location of User's Control
8
Disassembly and Reassembly
12
Installation and Service Instructions
16
Screen Adjustment
19
Picture Adjustment
19
Color Adjustment
19
Precautions in Reassembling
22
Function of Major Mechanical Parts
23
Adjustment, Replacement and Assembly of Mechanical Units
25
Adjustment of the Vcr Electrical Circuitry
45
Test Mode of DVD Section
47
Troubleshooting
60
Chassis Layout
72
IC Function List of DVD Section
73
Block Diagram of Tv Section
93
Block Diagram of Vcr Section
96
Block Diagram of DVD Section
100
Overall Schematic Diagram
101
Description of Schematic Diagram
102
Printed Wiring Board Assemblies
121
Replacement Parts List
133
Packing of the Set
163
