AL-2020/2035/2040/2050/2060 SIMULATION, TROUBLE CODES 10 - 34
66 05 Signal send mode
(Soft SW set value)
(AL-2060 only)
[Function]
Use to set the signal send mode (Soft SW set value).
Facsimile simulation design specifications.
[Operation]
07 Image memory content print
(AL-2060 only)
[Function]
Use to print the image memory content.
[Operation]
10 Image memory content clear
(AL-2060 only)
[Function]
Use to clear the image memory content.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
1 NO SIGNAL 13 7200bps(V34) 25 2400bps(V27ter)
2 33600bps(V34) 14 4800bps(V34) 26 300bps(FLAG)
3 31200bps(V34) 15 2400bps(V34) 27 2100Hz(CED)
4 28800bps(V34) 16 14400bps(V33) 28 1100Hz(CNG)
5 26400bps(V34) 17 12000bps(V33) 29 300bps(V21)
6 24000bps(V34) 18 14400bps(V17) 30 2100Hz(ANSam)
7 21600bps(V34) 19 12000bps(V17) 31 DUMMY RING
8 19200bps(V34) 20 9600bps(V17) 32 NO VOICE ANSWER
9 16800bps(V34) 21 7200bps(V17) 33 NO RING BACK TONE
10 14400bps(V34) 22 9600bps(V29) 34 LINE OFF HOOK
11 12000bps(V34) 23 7200bps(V29) 35 LINE ON HOOK
12 9600bps(V34) 24 4800bps(V27ter)
1) Initial display
2) 2-digit (1-35) with [Numeric] key / [ ] [ ] key / 2sec after
Pressing [ ] key or [ ] key reverses the sequence.
∗ [Clear] key: FAX control is terminated.
3) [OK] key
Send after setting
∗ [Clear] key: Returns to "1) Initial display".
SELECT OUTPUT SIGNAL
(2 DIGITS) No.___
No. (1-35)
1:NO SIGNAL
..... No. (1-35)
35:LINE ON HOOK
OUTPUTING SIGNAL SSW
PRESS CLEAR TO STOP
• When print is allowed
After completion of printing,
FAX control is terminated.
• When there is no print data
After 2 sec, FAX control is
terminated.
• When print is inhibited
After 2 sec, FAX control is
terminated.
PRINT STORED
NO DATA CAN NOT PRINT
• When there are some print data
After completion of memory clear, the buzzer
sounds.
Remains unchanged until the power is turned
off.
• When there are no print data
After completion of memory clear
After 2sec, FAX control is terminated.
CLEAR IMAGE MEMORY
CLEARED
PLEASE POWER OFF
CLEAR IMAGE MEMORY
CLEARED
