Sharp AL2020 Service Manual

AL-2020/2035/2040/2050/2060 FAX SOFT SWITCH 12 - 6
S
W
20
1 Line sound monitor range Bit No. 1 2
OFF
0
When a value outside
the set range is set,
the initial value is set.
OFF 0 0
2 Up to NSF signal send/
receive
01
0
All 1 0
3 Line monitor display 1: Yes 0: No No 0
4 Inhibited to use 0
5 Receivable memory
capacity
1: 64Kbyte 0: 128Kbyte
128Kbyte 0
6 Inhibited to use 0
7 0
8 0
S
W
21
1 Interval between
completion of
communication and the
next call
Binary input
6sec
0
2 Bit No.
Set range
12345678
0 to 255sec
0
3 0
4 0
5 0
6 1
7 1
8 0
S
W
22
1 Inhibited to use 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
S
W
23
1 Inhibited to use 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
S
W
24
1 Inhibited to use 0
2 0
3 Specified number
reception (ANTI JUNK
FAX)
Bit No. 3 4
Not set.
0
Refer to Main menu
“ANTI JUNK FAX”.
When a value outside
the set range is set,
the initial value is set.
Not set. 0 0
4 Receive inhibit 0 1
0
5 Inhibited to use 0
6 Document output setup in
reception
1: Collective output after
completion of reception
0: Output after reception
of every page
Collective output
after completion of
reception
1
7 Inhibited to use 0
8 Automatic reduction print 1: Allow 0: Inhibit
Allow 1
Refer to User program
“AUTO RCV
REDUCE”.
S
W
25
1 Automatic reduction rate
setup
Binary input
10%
1
2 Bit No.
Set range
1234
0 to 15%
0
3 1
4 0
5 Transmission end sound
tone
Bit No. 5 6
1000Hz
0
When a value outside
the set range is set,
the initial value is set.
550Hz 0 0
6 1000Hz 0 1
1
1700Hz 1 0
SW
NO.
Data
No.
Item Switch selection and contents of functions Initial value Remark
