Clearing Paper Jams
155
10. Trouble-
shooting
1 Press the side cover release ➊ and then open the side cover ➋.
2 Push the two heater roller release
levers down to release the heater roller.
• Caution!
The fusing unit (indicated in white at
right) becomes very hot during
operation. Do not touch the fusing unit.
3 If the jammed page is protruding from
the side of the machine, gently pull it
out. Take care not to tear the paper or
leave any torn pieces of paper in the
print compartment.
• If this clears the jam, go to Step 5.
• If you are unable to clear the jam in this
way, go to Step 4.
• Take care not to touch or allow other
objects to contact the drum (the green
cylinder). This may damage the drum.
Clearing jammed paper
1
2
To Next Page
