8
Preparation
TV (Rear)
RS-232C terminal
INPUT3 (HDMI)
terminal
INPUT7 (PC)
terminals
INPUT6 terminals INPUT5 terminals
Antenna input terminal
AC INPUT terminal
Headphone jack
INPUT2 (HDMI)
terminal
INPUT1 (HDMI)
terminals
INPUT4 terminals
MONITOR OUT terminals
DIGITAL AUDIO OUTPUT terminal
Regarding the headphone jack
• Use headphones with a stereo mini plug (Ø 3.5 mm).
• Be sure to unplug headphones from the jack when they are not
in use.
• The speakers do not output volume when headphones are
plugged in.
• The “Audio” menu cannot be operated when headphones are
plugged in.
• You can set the volume to different levels for each input source.
Volume display when headphones are plugged in
20
42A65M_en_b.indd 842A65M_en_b.indd 8 8/6/08 2:07:03 PM8/6/08 2:07:03 PM
