Note for this Service Manual
This Service Manual describes only the items related to the AR-5015. For the other items common with the AR-163, please refer to the AR-162/163
Service Manual (Document code: 00ZAR162//A1E). The table below shows which document(s) should be referred to for each section. (Refer to the
document marked with
.)
Section AR-163 AR-5015 Changed item
[ 1 ] NOTE FOR SERVICING
[ 2 ] SPECIFICATIONS Some specifications and option setup
[ 3 ] COSUMABLE PARTS
[ 4 ] EXTERNAL VIEW AND INTERNAL
STRUCTURE
Operation panel
[ 5 ] UNPACKING AND INSTALLATION
[ 6 ] ADJUSTMENTS The AR-5015 does not support installation of an option unit. (Note 1)
[ 7 ] SIMULATION
The AR-5015 does not support installation of an option unit. (Note 1)
[ 8 ] USER PROGRAM
The AR-5015 does not support installation of an option unit. (Note 1)
[ 9 ] TROUBLE CODE LIST
The AR-5015 does not support installation of an option unit. (Note 1)
[10] MAINTENANCE
The AR-5015 does not support installation of an option unit. (Note 1)
[11] DISASSEMBLLY AND ASSEMBLY
[12] FLASH ROM VERSION UP PROCEDURE
[13] ELECTRICAL CIRCUIT The AR-5015 does not support installation of an option unit. (Note 1)
Note 1: The AR-5015 does not support installation of an option unit such as SPF, paper feed unit, job separator, electronic sort unit, printer
expansion unit, and FAX expansion unit. Therefore, the descriptions on option units in each section of the reference document (AR-162/163
S/M) should be disregarded.
[ 2 ] SPECIFICATIONS
The table below shows the specifications of this model and the contents of changes from the AR-163.
Item AR-163 AR-5015
Copy speed 16 PPM 15 PPM
Multi-purpose tray 100 sheets 100 sheets
Standard tray 1 cassette (250 sheets) 1 cassette (250 sheets)
SOPM Yes (Depends on the destination) No
Option tray 1 tray Option No
2 tray Option No
Original detection No No
Original cover Yes Yes
SPF Option No
Electronic sort Option No
Job separator Option No
FAX expansion unit Option No
Printer expansion unit Option No
FAX expansion memory Option No
LCD panel Option No
Dust cover No No
APS Yes No
