AR-M236/M276/M237/M277 DISASSEMBLY, ASSEMBLY AND MAINTENANCE 10 - 16
Note: Check to confirm that the solenoid shaft is in the gate bracket,
and fix with the screw.
H. 2nd paper exit unit
(1) Switch
(2) Sensor
(3) Roller
I. Laser unit
(1) LSU
