GB-8
Press the THERMOSTAT button to set the
desired temperature.
AUTO/DRY MODE
• The temperature can
be changed in 1°C
increments within the
range of 2°C higher
to 2°C lower from the
temperature auto-
matically determined
by the air conditioner.
COOL/HEAT MODE
• The temperature
can be set within the
range of 18 to 32°C.
1
BASIC OPERATION
2
Press the ON/OFF button to start opera-
tion.
• The red OPERATION lamp ( ) on the unit
will light.
3
4
1
4
5
2
3
Press the MODE button to select the op-
eration mode.
AUTO HEAT COOL DRY
5
• In the DRY mode, the fan speed is preset to
AUTO and cannot be changed.
To turn off the unit, press the ON/OFF but-
ton again.
• The red OPERATION lamp ( ) on the unit
will turn off.
Press the FAN button to set the desired
fan speed.
AUTO SOFT LOW HIGH
(Example: 1°C higher)
(Example: 2°C lower)
To Next Page
