Sharp AY-XP12GHR User Manual

ENGLISH
GB-3
1 AUX. Button
2 Inlet (Air)
3 Open Panel
4 Deodorant Filter
5 Air Filters
6 Indicator
7 Receiver Window
8 Vertical Adjustment Louvres
9 Horizontal Adjustment Lou-
vres
10 Outlet (Air)
11 Power Supply Cord
12 Remote Control
13 PLASMACLUSTER Lamp
(blue)
14 TEMPERATURE INDICATOR
15 OUTDOOR Temp. Lamp
(green
)
16 ROOM Temp. Lamp
(green
)
17 FULL POWER Lamp
(green
)
18 TIMER Lamp (orange )
19 OPERATION Lamp (red
)
OUTDOOR UNIT
NOTE: -Actual units might vary slightly from those shown above.
INDOOR UNIT
20 Inlet (Air)
21 Refrigerant Tube and Inter-
connecting Cord
22 Drainage Hose
23 Outlet (Air)
13
14
15
16
17
18
19
20
21
22
23
PART NAMES
1
2
3
4
5
6
7
8
9
10
11
12

Sharp AY-XP12GHR Specifications

General

Brand	Sharp
Model	AY-XP12GHR
Category	Air Conditioner
Language	English
