Sharp CD-BP2000W

– 5 –
CD-BP2000W/210W/2000A/BK2000W/210W
Rear panel
1.AC Voltage Selector
2.AC Power Lead
3.FM 75 Ohms Aerial Terminal
4.FM Aerial Earth Terminal
5.AM Loop Aerial Input Socket
6.Speaker Terminals
7.Span Selector Switch
8.Video/Auxiliary (Audio Signal) Input Sockets
Speaker
1.Super Tweeters
2.Tweeter
3.Bass Reflex Duct
4.Woofer
5. Subwoofer
6.Main Speaker (Woofer, Tweeter and Super Tweeters)
Wire
7. Subwoofer Wire
1.Woofer
2.Tweeter
3.Super Tweeter
4. Subwoofer
5.Bass Reflex Ducts
6.Main Speaker (Woofer, Tweeter and Super Tweeter)
Wire
7. Subwoofer Wire
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
1
2
3
4
5
6
7
1.Super Tweeter
2.Tweeter
3.Bass Reflex Duct
4.Woofer
5. Subwoofer
6.Main Speaker (Woofer, Tweeter and Super Tweeter)
Wire
7. Subwoofer Wire
1
2
3
4
5
6
7
CP-BP2000
CP-BP210
CP-BP2000A
