Sharp CD-BP2000W

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BP2000W/210W/2000A/BK2000W/210W
CD-BP2000W/210W/2000A/BK2000W/210W
INTEGRATED CIRCUITS
IC1 VHILA9235M/-1 J AQ Servo Amp.,LA9235M
IC2 VHILC78641E-1 J AV Servo/Signal Control,LC78641E
IC3 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled
Driver,M63001FP
IC101 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL (Tuner),LC72131
IC303 VHILA1832S/-1 J AN FM IF Det./FM Mpx./AM IF,
LA1832S
IC561~563 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
IC601 VHILC75341/-1 J AM Audio Processor,LC75341
IC701 RH-IX0334AWZZ J AX System Microcomputer,
IX0334AW
IC702 VHIBU2092/F-1 J Input/Output Expander,BU2092
IC703 VHIKIA7042AP1 J AC Reset,KIA7042AP
IC801 VHIKIA7805P-1 J AF Voltage Regulator,KIA7805P
IC802 VHIKIA7810AP1 J AF Voltage Regulator,KIA7810AP
IC901 VHISTK40271-1 J AZ Power AMP.,STK40271
IC902 VHISTK40204-1 J AX Power AMP.,STK40204
IC903 VHIKIA4558P-1 J AC Ope Amp.,KIA4558P
ICK1 VHIM65856SP-1 J AX Mic Amp.,M65856SP
[BK2000W/BK210W Only]
TRANSISTORS
Q1 VS2SC3203Y/-1 J Silicon,NPN,2SC3203 Y
Q2 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q3 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q103~106 VS2SC1845F/-1 J AC Silicon,NPN,2SC1845 F
Q107,108 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q109 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q110,111 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q121,122 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q124 VS2SA1015GR-1 J AB Silicon,PNP,2SA1015 GR
Q126 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
Q128 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q302 VSKTC3194Y/-1 J AD Silicon,NPN,KTC3194 Y
Q360 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q603~606 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q701~703 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q704,705 VSKTA1271Y/-1 J AC Silicon,PNP,KTA1271 Y
Q706,707 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q708 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q709 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q710~712 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q801 VSKTA1274Y-1T J Silicon,PNP,KTA1274 Y
Q802 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q821 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
Q823 VSKTC2026//-1 J AF Silicon,NPN,KTC2026
Q901~909 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q910 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
QK1 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
[BK2000W/BK210W Only]
DIODES
D21,22 VHDDS1SS133-1 J AB Silicon,DS1SS133
D301,302 VHD1SS133//-1 J AA Silicon,1SS133
D305 VHD1SS133//-1 J AA Silicon,1SS133
D561~566 VHD1SS133//-1 J AA Silicon,1SS133
D601,602 VHD1SS133//-1 J AA Silicon,1SS133
D603,604 VHD1SS133//-1 J AA Silicon,1SS133
[BK2000W/BK210W Only]
D707 VHD1SS133//-1 J AA Silicon,1SS133
D710~718 VHD1SS133//-1 J AA Silicon,1SS133
D720,721 VHD1SS133//-1 J AA Silicon,1SS133
D801 VHD1SS133//-1 J AA Silicon,1SS133
D802,803 VHDTS6B04GM-1 J AP Silicon,TS6B04GM
D804~810 VHD1N4004S/-1 J AB Silicon,1N4004S
D811 VHD1SS133//-1 J AA Silicon,1SS133
D812~815 VHD1N4004S/-1 J AB Silicon,1N4004S
D816,817 VHD1SS133//-1 J AA Silicon,1SS133
D818 VHD1N4004S/-1 J AB Silicon,1N4004S
D901~909 VHD1SS133//-1 J AA Silicon,1SS133
LED701~704 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED705~707 VHP4204UGT7-1 J AD LED,Green,4204UGT7
LED708 VHP4204UYT7-1 J AD LED,Yellow,4204UYT7
LED722 VHP4204SRT7-1 J AD LED,Red,4204SRT7
ZD61 VHEDZ3R9BSB-1 J AC Zener,3.9V,DZ3.9BSB
ZD351 VHEMTZJ5R1B-1 J AC Zener,5.1V,MTZJ5.1B
ZD561 VHEMTZJ6R2C-1 J AC Zener,6.2V,MTZJ6.2C
ZD801 VHEMTZJ360C-1 J AB Zener,36V,MTZJ36C
ZD802 VHEMTZJ6R2A-1 J AA Zener,6.2V,MTZJ6.2A
ZD803 VHEMTZJ130C-1 J AB Zener,13V,MTZJ13C
ZDK1 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
[BK2000W/BK210W Only]
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
CF303 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T301 RCILB0065AWZZ J AC FM,OSC
T302 RCILI0017AWZZ J AB FM IF
T303 RCILA0052AWZZ J AE AM Tracking
T306 RCILB0058AWZZ J AC AM,OSC
T351 RCILI0019AWZZ J AD AM IF
! T801 RTRNP0304AWZZ J Power
! T802 RTRNP0239AWZZ J AP Power
COILS
L61 VP-XHR82K0000 J AC 0.82 µH
L62 VP-XH2R2K0000 J AB 2.2 µH,Choke
L104 VP-MK331K0000 J AB 330 µH,Choke
L312 RCILR0056AWZZ J AB FM RF
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L701 VP-DH101K0000 J AB 100 µH,Choke
L902~905 RCILZ0137AFZZ J AA 0.29 µH
VARIABLE RESISTORS
VRK1 92LVRR1674A J AF 20 kohms (B) [Mic 1 Volume]
[BK2000W/BK210W Only]
VRK2 92LVRR1674A J AF 20 kohms (B) [Mic 2 Volume]
[BK2000W/BK210W Only]
VARIABLE CAPACTORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCSVC211C/-1 J AG Variable Capacitance,SVC211C
VIBRATORS
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0002AWZZ J AH Crystal,4.5 MHz
XL1 92LCRSTL1746AT J AH Crystal,16.93 MHz
XL701 RCRSP0003AWZZ J AH Crystal,4.1943 MHz
CAPACITORS
C6 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C7 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C8 VCKYTV1HB104K J AB 0.1 µF,50V
C11 RC-EZY474AF0J J 0.47 µF,6.3V,Electrolytic
C12 VCKYTV1HB104K J AB 0.1 µF,50V
C13 VCKYTV1HB103K J AA 0.01 µF,50V
C14 VCKYTV1EF334Z J AB 0.33 µF,25V
C16 VCCSPA1HL6R0J J AA 6 pF,50V
C17 VCKYTV1HB472K J AA 0.0047 µF,50V
C18 VCCCTV1HH3R0C J AA 3 pF (CH),50V
C19 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C20,21 VCKYTV1HB104K J AB 0.1 µF,50V
C22 VCKYTV1HB101K J AA 100 pF,50V
C23 VCKYTV1HB473K J AA 0.047 µF,50V
C24 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C25 VCKYTV1HB104K J AB 0.1 µF,50V
C26 VCKYTV1HB473K J AA 0.047 µF,50V
C27 VCKYTV1HB104K J AB 0.1 µF,50V
– 1 –
