PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BP2000W/210W/2000A/BK2000W/210W
C817 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C818 VCEAZA1VW477M J 470 µF,35V,Electrolytic
C819 VCEAZA0JW108M J AC 1000 µF,6.3V,Electrolytic
C820 VCEAZW1EW338M J AG 3300 µF,25V,Electrolytic
C821,822 VCKZPA1HF223Z J AA 0.022 µF,50V
C823 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C824,825 VCKZPA1HF223Z J AA 0.022 µF,50V
C826 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C827 VCEAZA1EW226M J AB 22 µF,25V,Electrolytic
C828,829 VCKZPA1HF223Z J AA 0.022 µF,50V
C830 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C831 RC-KZ002LAWZZ J AE 0.0047 µF,250V,Ceramic
C832,833 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C834 VCEAZV1JW107M J 100 µF,63V,Electrolytic
C901,902 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C903,904 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C905 VCKZPA1HF223Z J AA 0.022 µF,50V
C906,907 VCCSPA1HL221J J AA 220 pF,50V
C908 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C909,910 VCCSPA1HL150J J AA 15 pF,50V
C911 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C912 VCKZPA1HF223Z J AA 0.022 µF,50V
C914 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C918,919 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C920,921 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C922,923 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C924,925 VCKZPA1HF223Z J AA 0.022 µF,50V
C926,927 VCCSPA1HL221J J AA 220 pF,50V
C928,929 VCCSPA1HL150J J AA 15 pF,50V
C930,931 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C932 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C935,936 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C937 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C938 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C941,942 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C943,944 VCTYPA1CX102K J AA 0.001 µF,16V
C945,946 VCFYHA1HA154K J 0.15 µF,50V,Thin Film
C947,948 VCCSPA1HL101J J AA 100 pF,50V
C949,950 VCKZPA1HF223Z J AA 0.022 µF,50V
C951,952 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C953 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C954,955 VCFYHA1HA154K J 0.15 µF,50V,Thin Film
C956 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C957 VCKZPA1HF223Z J AA 0.022 µF,50V
C958,959 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
C960,961 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C986 VCKZPA1HF223Z J AA 0.022 µF,50V
C988 VCKYBT1HB102K J AA 0.001 µF,50V
CK1 VCTYPA1CX103K J AA 0.01 µF,16V
[BK2000W/BK210W Only]
CK2 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK3 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK4 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK5,6 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK7 VCFYHA1HA474J J AD 0.47 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK8 RC-EZY475AF1H J AB 4.7 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK9 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK10,11 VCFYDA1HA104J J AB 0.1 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK12 RC-EZY225AF1H J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK13 VCTYPA1CX472K J AA 0.0047 µF,16V
[BK2000W/BK210W Only]
CK14 VCTYPA1CX102K J AA 0.001 µF,16V
[BK2000W/BK210W Only]
CK15 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
[BK2000W/BK210W Only]
CK16 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK17 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
[BK2000W/BK210W Only]
CK18 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
[BK2000W/BK210W Only]
CK19 VCKZPA1HF223Z J AA 0.022 µF,50V [BK2000W/
BK210W Only]
CK20 VCFYHA1HA224J J AC 0.22 µF,50V,Thin Film
[BK2000W/BK210W Only]
CK21 VCQYKA1HM683K J AB 0.068 µF,50V,Mylar
[BK2000W/BK210W Only]
CK22 VCTYPA1CX472K J AA 0.0047 µF,16V
[BK2000W/BK210W Only]
CK23 VCTYPA1CX102K J AA 0.001 µF,16V
[BK2000W/BK210W Only]
CK24~26 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK29,30 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
CK31 VCFYDA1HA154J J AB 0.15 µF,50V,Polyester
[BK2000W/BK210W Only]
CK32 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
[BK2000W/BK210W Only]
CK33~35 VCCSPA1HL470J J AA 47 pF,50V
[BK2000W/BK210W Only]
CK41 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
[BK2000W/BK210W Only]
CK42 VCKZPA1HF223Z J AA 0.022 µF,50V
[BK2000W/BK210W Only]
CK43,44 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
[BK2000W/BK210W Only]
CK72 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
[BK2000W/BK210W Only]
CK73,74 VCEAZA1HW225M J AB 2.2 µF,50V,Electrolytic
[BK2000W/BK210W Only]
RESISTORS
VRD-MN2BD000C J AA 0 ohm,Jumper,ø1.4×3.5mm,Ivory
VRD-MN2BD000J J 0 ohms,1/8W
VRS-TV2AB000J J AA 0 ohm,Jumper,1.25×2mm,Green
R3 VRS-TV2AB104J J AA 100 kohm,1/10W
R4 VRS-TV2AB103J J AA 10 kohm,1/10W
R5 VRS-TV2AB393J J AA 39 kohms,1/10W
R6 VRS-TV2AB273J J AA 27 kohms,1/10W
R7 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R8 VRS-TV2AB331J J AA 330 ohms,1/10W
R10 VRS-TV2AB273J J AA 27 kohms,1/10W
R11 VRS-TV2AB123J J AA 12 kohms,1/10W
R12,13 VRS-TV2AB681J J AA 680 ohms,1/10W
R14 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R15 VRS-TV2AB103J J AA 10 kohm,1/10W
R16 VRD-ST2CD103J J AA 10 kohm,1/6W
R17 VRD-ST2CD102J J AA 1 kohm,1/6W
R19 VRD-ST2CD470J J AA 47 ohms,1/6W
R20 VRS-TV2AB221J J AA 220 ohms,1/10W
R21,22 VRS-TV2AB471J J AA 470 ohms,1/10W
R25 VRD-ST2CD103J J AA 10 kohm,1/6W
R35 VRD-ST2CD102J J AA 1 kohm,1/6W
R38 VRD-ST2CD271J J AA 270 ohms,1/6W
R39 VRD-ST2CD471J J AA 470 ohms,1/6W
R40 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R42 VRS-TV2AB124J J AA 120 kohms,1/10W
R43 VRS-TV2AB224J J AA 220 kohms,1/10W
R44 VRD-ST2CD102J J AA 1 kohm,1/6W
R45 VRS-TV2AB122J J AA 1.2 kohms,1/10W
R46 VRS-TV2AB102J J AA 1 kohm,1/10W
R47 VRD-ST2EE3R3J J AA 3.3 ohms,1/4W
R48 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R50 VRS-TV2AB470J J AA 47 ohms,1/10W
R51~54 VRS-TV2AB683J J AA 68 kohms,1/10W
R55,56 VRD-ST2CD683J J AA 68 kohms,1/6W
R58 VRD-ST2CD221J J AA 220 ohms,1/6W
R71~78 VRD-ST2CD102J J AA 1 kohm,1/6W
R79 VRS-TV2AB155J J AA 1.5 Mohms,1/10W
R80 VRD-ST2CD105J J AA 1 Mohm,1/6W
R81,82 VRS-TV2AB222J J AA 2.2 kohms,1/10W
R83,84 VRS-TV2AB103J J AA 10 kohm,1/10W
R88 VRS-TV2AB682J J AA 6.8 kohms,1/10W
R94,95 VRS-TV2AB103J J AA 10 kohm,1/10W
R101 VRD-MN2BD102J J AA 1 kohm,1/8W
R102 VRD-ST2CD102J J AA 1 kohm,1/6W
R103,104 VRD-MN2BD222J J AA 2.2 kohms,1/8W
R105,106 VRD-MN2BD332J J AA 3.3 kohms,1/8W
R107,108 VRD-MN2BD473J J AA 47 kohms,1/8W
R109,110 VRD-MN2BD472J J AA 4.7 kohms,1/8W
R111 VRD-MN2BD153J J AA 15 kohms,1/8W
R112 VRD-ST2CD153J J AA 15 kohms,1/6W
– 3 –
