Sharp CD-BP2000W

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BP2000W/210W/2000A/BK2000W/210W
CNS3A/B QCNWN1539AWZZ J AE Connector Ass’y,6/6Pin
CNS803 QCNWN1542AWZZ J AC Connector,2Pin
CNS901 QCNCW010UAWZZ J AD Socket,19Pin
! F800,801 92LFUSET402E J AD Fuse,T4A L 250V
! F802,803 92LFUSET502E J AC Fuse,T5A L 250V
! F805 92LFUSE-T202E J AD Fuse,T2A L 250V
FC701 QCNWN1545AWZZ J AG Flat Cable,29Pin
FC702 QCNWN1544AWZZ J AE Flat Cable,13Pin
FL701 VVKBJ744GNK-1 J BD FL Display
FW801 QCNWN1543AWZZ J AD Flat Wire,5Pin
JK1,2 QJAKJ0007AWZZ J AF Jack,Mic 1,2
JK601 QSOCJ0213AWZZ J AE Jack,Video In
JK670 QJAKM0010AWZZ J AF Jack,Headphones
JOG701 QSW-Z0010AWZZ J AF Switch,Push Type [JOG]
LG901,902 QLUGP0001AWZZ J AC Lug
LUG1 QLUGP0002AWZZ J AB Lug
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 92LTWMEN7E6Y J AR Motor with Worm Pulley
[T/T Up/Down Loading]
M901 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
RL801 RRLYD0001SJZZ J AQ Relay
RL901,902 RRLYD0004AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO302 QTANC0204AWZZ J Terminal,Antenna
SO901 QTANA0806AWZZ J AG Terminal,Speaker
SW1 SWMPU10780MLB J Switch,Push Type [Open/Close]
SW2 SWMPU11470MLB J Switch,Push Type [Clamp]
SW3 SWMPU11470MLB J Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW601 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
SW701 92LSWICH1401AT J AC Switch,Key Type
[ON/STAND-BY]
SW702 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW703 92LSWICH1401AT J AC Switch,Key Type [TIMER]
SW709 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW710 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW711 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW712 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW713 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW714 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
SW715 92LSWICH1401AT J AC Switch,Key Type
[X-BASS/MEMO]
SW716 92LSWICH1401AT J AC Switch,Key Type [EQUALIZER]
SW722 92LSWICH1401AT J AC Switch,Key Type [CD]
SW723 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW724 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW726 92LSWICH1401AT J AC Switch,Key Type
[PRESET DOWN]
SW727 92LSWICH1401AT J AC Switch,Key Type [PREST UP]
SW728 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW729 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW730 92LSWICH1401AT J AC Switch,Key Type [REV PLAY]
SW731 92LSWICH1401AT J AC Switch,Key Type [REC/PAUSE]
SW732 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW733 92LSWICH1401AT J AC Switch,Key Type [VIDEO/AUX]
SW734 92LSWICH1401AT J AC Switch,Key Type [TUNER]
SW735 92LSWICH1401AT J AC Switch,Key Type [REV MODE]
! SW801 QSOCE0008AWZZ J AH Switch,Slide Type
[Voltage Selector]
WT601 QCNCW012EAWZZ J AC Plug,5Pin
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0080AWZZ J AC Rail,Guide
304 NSFTM0020AWFW J AD Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1LXASY J BD Pickup Unit Ass’y
306- 1 ———— –– Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR2790CASY J BB Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 92LCAB3338AASY J Front Cabinet Ass’y [BP2000W]
201 92LCAB3339AASY J Front Cabinet Ass’y [BK2000W]
201 92LCAB3341AASY J Front Cabinet Ass’y [BP210W]
201 92LCAB3342AASY J Front Cabinet Ass’y [BK210W]
201 92LCAB3349AASY J Front Cabinet Ass’y [BP2000A]
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 GDORF0074AWSA J AE Holder,Cassette,Tape 1
201- 3 GDORF0075AWSA J AE Holder,Cassette,Tape 2
201- 4 GCOVA1251AWSA J AH Cover,Cassette,Tape 1
201- 5 GCOVA1298AWSA J AE Cover,Cassette,Tape 2
201- 6 HDECQ0521AWSA J AD Panel,Cassette,Tape 1
201- 7 HDECQ0522AWSA J AD Panel,Cassette,Tape 2
201- 8 HDECQ0579AWSA J Panel,Amp [BP2000A/BP2000W]
201- 8 HDECQ0583AWSA J Panel Amp [BP210W]
201- 8 HDECQ0584AWSA J Panel Amp [BK210W]
201- 8 HDECQ0585AWSA J Panel,Amp. [BK2000W]
201- 9 HDECQ0566AWSA J Decoration Plate
201-10 JKNBZ0665AWSA J AF Knob,Disc Control
201-11 JKNBZ0683AWSA J AG Knob,Center Operation
201-12 JKNBZ0714AWSA J AF Knob,On/Stand-By/Clock
201-13 JKNBZ0658AWSA J AF Knob,Function,A
201-14 JKNBZ0659AWSA J AF Knob,Function,B
201-15 JKNBZ0660AWSA J AF Knob,Tuning
201-16 JKNBZ0661AWSA J AE Knob,Dimmer
201-17 HDECQ0525AWSA J AC Volume Ring
201-19 GCOVA1256AWSA J AB Cover,LED,Preset
201-20 GCOVA1258AWSA J AB Cover,LED,Power
201-21 MLIFP0008AWZZ J AD Damper
201-22 MSPRD0138AWFJ J Spring,Cassette,Tape 1
201-23 MSPRD0127AWFJ J AB Spring,Cassette,Tape 2
201-24 92LBADGE1671A J AC Badge,SHARP
201-25 GCOVA1277AWSA J AB Cover,LED,Operation
201-26 PSHEM0008AWZZ J Sheet,Shield
201-27 GCOVA1260AWSA J AB Cover,LED,Disc Control A
201-28 GCOVA1275AWSA J AB Cover,LED,Disc Control B
201-29 GCOVA1276AWSA J AB Cover,LED,Disc Control C
201-30 PSHEP0042AWZZ J Spacer,Operation Knob A
201-31 PSHEP0043AWZZ J Spacer,Operation Knob B
202 92LCAB3303BASY J Side Panel Ass’y,Left
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3303CASY J Side Panel Ass’y,Right
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3303AASY J CD Tray Cover Ass’y
204- 1 ———— –– Cover,CD Tray
(Not Replacement Item)
204- 2 GCOVA1254AWSA J AE Cover,CD Tray Panel,Left
204- 3 GCOVA1255AWSA J AE Cover,CD Tray Panel,Right
205 GCAB-1184AWSA J AP Top Cabinet
206 GITAR0586AWSA J Rear Panel [BP2000W]
206 GITAR0595AWSA J Rear Panel [BP210W]
206 GITAR0587AWSA J Rear Panel [BK2000W]
206 GITAR0597AWSA J Rear Panel [BK210W]
206 GITAR0605AWSA J Rear Panel [BP2000A]
207 JKNBK0072AWSA J AE Knob,Volume
208 LANGK0110AWFW1J AD Bracket,Cassette Lock,Tape 1
209 LANGK0111AWFW1J AD Bracket,Cassette Lock,Tape 2
210 LANGK0188AWFW J AF Bracket,Fan Support
211 LANGT0042AWFW J AC Bracket,PWB Support A
212 LBSHC0002AWZZ J AD Bushing,AC Power Supply Cord
213 LCHSM0096AWFW J AR Main Chassis
214 LHLDZ1242AWZZ J AE Holder,FL Display
219 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
220 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
221 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
222 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
223 NFANP0001AWZZ J AD Rotary Fan
224 92LPT0331105 J AM Turntable
225 PCUSG0022AWZZ J AB Cushion,Leg
226 PRDAR0149AWFW J AP Heat Sink,Main
227 PRDAR0150AWFW J AS Heat Sink,Sub,A
– 6 –
